LRO View of Earth

Published by Klaus Schmidt on Wed May 7, 2014 6:42 pm via: NASA
Share
More share options
Tools
Tags

NASA’s Lunar Reconnaissance Orbiter (LRO) experiences 12 “earthrises” every day, however LROC (short for LRO Camera)  is almost always busy imaging the lunar surface so only rarely does an opportunity arise such that LROC can capture a view of Earth. On Feb. 1, 2014, LRO pitched forward while approaching the moon’s north pole allowing the LROC Wide Angle Camera to capture Earth rising above Rozhdestvenskiy crater (112 miles, or 180 km, in diameter).

The LROC WAC is very different than most digital cameras. Typically resolution is reported as the number pixels in a single image; a cell phone camera today has more than 5 million pixels (5 megapixels). A single WAC frame has only 9,856 pixels, however the WAC builds up a much larger image by exposing a series of images (or frames) as LRO progresses in its orbit; this type of imaging is called “push-frame.” Over a full month as the LRO orbit track progresses around the moon the WAC builds up a collection of images that covers the entire globe.

This image, captured Feb. 1, 2014, shows a colorized view of Earth from the moon-based perspective of NASA's Lunar Reconnaissance Orbiter. Image Credit: NASA/Goddard/Arizona State University

This image, captured Feb. 1, 2014, shows a colorized view of Earth from the moon-based perspective of NASA's Lunar Reconnaissance Orbiter. Image Credit: NASA/Goddard/Arizona State University

Occasionally LRO points off into space to acquire observations of the moon’s exosphere and perform instrument calibration measurements. During these slews sometimes Earth (and other planets) pass through the WAC’s field of view and dramatic images such as the one shown here are acquired. In the image above, the moon is a grayscale composite of the first six frames of the WAC observation (while the spacecraft was still actively slewing), using visible bands 604 nm (nanometers), 643 nm and 689 nm. Earth is a color composite of later frames, using  the 415 nm, 566 nm and 604 nm bands as blue, green and red, respectively. These wavelengths were picked as they match well the response of the human eye, so the colors are very close to true, that is what the average person might see. Also, in this image the relative brightness between Earth and the moon is correct. Note how much brighter Earth is relative to the moon.

In the animaiton, the “venetian blind” banding demonstrates how a WAC image is built up frame-by-frame. The gaps between the frames are due to the real separation of the WAC filters on the CCD. The longest wavelength (689 nm) band is at the bottom of the scene, and the shortest (415 nm) is at the top; note how Earth is brighter when it enters the top band due to the blue from the ocean. The frames were acquired at two second intervals, so the total time to collect the sequence was five minutes. The video is about 20 times faster than reality.

This animation of LROC WAC observations shows an apparent rising Earth from the moons limb. Image Credit: NASA/Goddard/Arizona State University

This animation of LROC WAC observations shows an apparent rising Earth from the moon's limb. Image Credit: NASA/Goddard/Arizona State University
