Safety Component Arrives for Orion Flight Test

Published by Klaus Schmidt on Tue Mar 26, 2013 5:24 am via: NASA
Share
More share options
Tools
Tags

A critical segment of Orion’s Launch Abort System, the launch abort motor, recently arrived at NASA’s Kennedy Space Center in Florida for Exploration Flight Test (EFT)-1. Built by Alliant Techsystems (ATK), the abort motor will be used to pull the crew to safety and position the module for a safe landing in case of an emergency during future missions.

The other segments of the Launch Abort System are the fairing, the jettison motor and the attitude control motor. They will be assembled together horizontally in the Launch Abort System Facility (LASF) beginning in April. To prepare for EFT-1, the system will be attached to the top of the Orion crew module in the Astrotech processing facility in Titusville, Fla., for the flight test, scheduled for September 2014.

At NASA’s Kennedy Space Center in Florida, technicians help remove the Alliant Techsystems (ATK) launch abort motor from a truck after arrival at the Launch Abort System Facility. Photo credit: NASA/Charisse Nahser

At NASA’s Kennedy Space Center in Florida, technicians help remove the Alliant Techsystems (ATK) launch abort motor from a truck after arrival at the Launch Abort System Facility. Photo credit: NASA/Charisse Nahser

During a media viewing of the launch abort motor, Brian Duffy, vice president and program manager for Exploration Systems with ATK Aerospace Group, said it is a one-of-a-kind piece of hardware that is uniquely engineered. The motor is loaded with inert solid fuel because EFT-1 will be an uncrewed flight test.

While only the jettison motor will be active during the 2014 test to enable the entire system to detach from Orion during ascent, the system will provide aerodynamics and environmental loads data.

“In the future, crews aboard the spacecraft are going to feel very comfortable with the abort motor and the entire abort system,” said Duffy, who is a four-time space shuttle mission crew member.

Brian Duffy, ATK Aerospace Systems' vice president and manager of Exploration Systems, talks with members of the media during a viewing of ATK’s launch abort motor inside the Launch Abort System Facility at Kennedy Space Center. Photo credit: NASA/Dimitri Gerondidakis

Brian Duffy, ATK Aerospace Systems' vice president and manager of Exploration Systems, talks with members of the media during a viewing of ATK’s launch abort motor inside the Launch Abort System Facility at Kennedy Space Center. Photo credit: NASA/Dimitri Gerondidakis

“From the time the crew is on the launch pad, until they’re in part of the flight profile, and they no longer need an abort system, they’ll have this system on board,” Duffy said. “And when it’s no longer required it will be jettisoned and won’t be reused.”

According to Duffy, the abort motor is designed to ignite at the top end, away from where it is attached to Orion for thermal and acoustic reasons and to protect the integrity of the crew module. The unique design of the attitude control system features a reverse flow and the half-million pounds of thrust would turn the 28,000-pound crew module about 180 degrees so that it would re-enter Earth’s atmosphere with the heat shield facing down.

The launch abort motor is one of the components of Orion’s Launch Abort System, which will be used for Exploration Flight Test-1.  Image credit: NASA/Dimitri Gerondidakis

The launch abort motor is one of the components of Orion’s Launch Abort System, which will be used for Exploration Flight Test-1. Image credit: NASA/Dimitri Gerondidakis

Duffy said if the motor was fired at the launch pad to escape a bad situation, it would actually extract Orion and move it about a mile in the air and a mile downrange so that it could reorient before its parachutes deploy.

“The crew would have the means to reach the ground safely from the time they get in the spacecraft,” Duffy said. “It’s a very smart and capable system.”

An artist concept shows Orion as it will appear in space for the Exploration Flight Test-1 attached to a Delta IV second stage.  Image credit: NASA

An artist concept shows Orion as it will appear in space for the Exploration Flight Test-1 attached to a Delta IV second stage. Image credit: NASA

For EFT-1, NASA will collect the data on the environment that the spacecraft, including the abort system, will experience during its ascent. It will be instrumented for data, Duffy said, even though there will be no humans aboard.

EFT-1 will be launched on a United Launch Alliance Delta IV Heavy rocket. NASA’s Space Launch System, currently in development, will launch future Orion spacecraft with an active launch abort motor and system atop.
